Dixie Chopper 2014 Xcaliber Twin Mower Throttle Assembly Parts

Item

Part No.

Description

68251

Throttle Assembly (Twin) - 68251

97010

Throttle Bracket (Twin) - 97010

600062

Throttle Handle (Hon/Kaw/Twin) - 600062

600075

Throttle Cable 62in - 600075

W-125

Washer W-125

W-104

3/8in. Flat Washer W-104

N-107

3/8in-16 Nyloc Nut N-107

B-165

Bolt-3/8-16x2 HHCS PT Gr.5, Clear Zinc

C-105

Clip - #10 - 24 Nut Clip f/Throttle

68271

Bracket - Throttle Fender Stainless LH

Item

Part No.

Description

67258

Throttle Grip (Hon/Kaw/Twin) - 67258

B-103

Bolt-1/4-20x1/2 HHCS FT, SS

W-153

Washer - 1/4 SS Flat

N-101

Nut - 1/4 - 20 SS Whiz N-101

B-203

Bolt-#10-24x3/4 HHCS FT, SS

W-152

Washer - #10 Flat SS

N-134

Nut - 5/16 - 18 x Large Flange Lock Gr.F, Clear Zinc

B-313

Bolt - 5/16-18X7/8 HHCS FT Gr.5, Clear Zinc

W-113

5/16in. Flat Washer W-113

Products (Total Items: 13)

Sort by:

Dixie Chopper N-101 NUT-1/4-20 FLANGE WHIZ 18-8 SS

Part Number:N-101

Specs: 1/4 - 20 SS Whiz

View More Details

$4.04

Dixie Chopper W-104 WASHER,FLAT 0.063"THK-CLR ZINC

Part Number:W-104

Specs: 3/8in.

Model: 2044 (2008), 2250 (2012), 2344 (2009), 2344 (2010), 2344 (2011), 2350 (2008), 2350 (2009), 2350 (2010), 2460 (2012), 2560 (2008) and many more

View More Details

$4.04

Dixie Chopper W-113 WASHER-5/16X7/8X.08 FLAT

Part Number:W-113

Specs: 5/16in.

Model: 2044 (2008), 2250 (2012), 2344 (2009), 2344 (2010), 2344 (2011), 2350 (2008), 2350 (2009), 2350 (2010), 2460 (2012), 2560 (2008) and many more

View More Details

$4.04

Dixie Chopper N-107 NUT-3/8-16 NYLOC GR.ACLR ZINC

Part Number:N-107

Specs: 3/8”/16

Model: 2044 (2008), 2250 (2012), 2344 (2009), 2344 (2010), 2344 (2011), 2350 (2008), 2350 (2009), 2350 (2010), 2460 (2012) and many more

View More Details

$4.04

Dixie Chopper 68271 BRKT-THROTTLE FENDER STAINLESS

Part Number:68271

Model: SP3200-72 (2004), XT3200-72 (2004), XXG5400-72 (2005), XXW4000-72 (2002), XXW4600-72 (2003), XXW4600-72 (2004), XXW4600-72 (2005) and many more.

View More Details

$41.43

Dixie Chopper B-103 BOLT-1/4-20X1/2 HHCS FT; SS

Part Number:B-103

Specs: 1/4-20in. x 1/2in.

View More Details

$4.04

Dixie Chopper B-165 BOLT-3/8-16X2 HHCS PT GR.5

Part Number:B-165

Specs: 3/8"-16 / 2"

Model: 2044 (2008), 2250 (2012), 2344 (2009), 2344 (2010), 2344 (2011), 2350 (2008), 2350 (2009), 2350 (2010), 2460 (2012), 2560 (2008) and many more

View More Details

$4.04

Dixie Chopper B-203 BOLT-#10-24X3/4 HHCS FT; SS

Part Number:B-203

Specs: 10-24 / 3/4"

Model: 2250 (2012), 2460 (2012), 3066LP (2012), 3074LP (2012), 3360 (2008), 3372 (2008), Classic 2550 (2008), Classic 2550 (2009) and many more

View More Details

$4.04

Dixie Chopper B-313 BOLT-5/16-18X7/8 HHCS FT GR.5

Part Number:B-313

Specs: 5/16"-18 / 7/8"

Model: 3066LP (2012), 3074LP (2012), 3360 (2008), 3372 (2008), Classic 2550 (2008), Classic 2550 (2009), Classic 2550 (2010) and many more

View More Details

$4.04

Dixie Chopper C-105 CLIP-ON NUT #10-24 NO-SLIP

Part Number:C-105

Model: 2250 (2012), 2460 (2012), 3066LP (2012), 3074LP (2012), 3360 (2008), 3372 (2008), Classic 2550 (2008), Classic 2550 (2009) and many more

View More Details

$4.04

Dixie Chopper N-134 NUT-5/16-18 LARGE FLANGE LOCK

Part Number:N-134

Specs: 5/16 - 18 x Large Flange Lock Gr.F

View More Details

$4.04

Dixie Chopper W-152 WASHER-#10 FLAT SS; PLAIN

Part Number:W-152

Model: 2250 (2012), 2460 (2012), 3066LP (2012), 3074LP (2012), 3360 (2008), 3372 (2008), Classic 2550 (2008), Classic 2550 (2009) and many more.

View More Details

$4.04

Dixie Chopper W-153 WASHER,FLAT 1/4 SS-PLAIN

Part Number:W-153

Model: 2250 (2012), 2344 (2010), 2344 (2011), 2350 (2010), 2460 (2012), 2560 (2010), 2650 (2011), 2750 (2010), 2750 (2011), 2750 (2012) and many more.

View More Details

$4.04
